GD 210 Printer
Buy Best GD 210 Printer Machine
Suitable to print 1 ltr to 5 ltr (0.26 to 1.32 US Gallons)
GD 210 Printer Specifications
| Unit | Value |
|---|---|
| Min. & Max Dia. | 80mm x 210mm |
| Min. & Max. Height | 100mm x 200mm |
| Max Print Area | 630mm (L) x 180mm (H) |
| Electric Motor Drive | Ac Gear motor 5 HP, 3 Phase, 50Hzs. with inverter for fine speed control |
| Pneumatic Pressure | @8-10 kg/cm2 |
| Air Consumption | @12m3/hr |
| Total Power Consumption | 9.5 kilowatts |
| Max. Impression | @ 2200/hr (4 Ltr Bucket) |
| Total Machine Weight | 5500 kgs |
GD 210 Printer Machine Features
Features
- Auto Loading.
- Flame treatment with auto ignition.
- Instantaneous UV drying.
- Auto Ejection with exit conveyor.
- Lower ink consumption.
- Less Floor space.
- AC Motor with AC frequency inverter for variable speed, acceleration and deceleration control.
- Anti-backlash plate cylinder gear.
- Micrometer lateral and radial plate cylinder adjustment.
- Complete vacuum system with pump that holds container on mandrels at neccessary position.
- Positive timing through out machine.
Optional
- Zeromax Drive for auto ink control.
- Magnetic Cylinder from USA
- Corona System.
- Offline Registration.
- PLC Based Ink Transfer System.
- Maintenance Free Ink Distribution System.
REQUEST TECHNICAL QUOTATION
Complete the form below to receive detailed technical documentation and a customized quote for the GD 210 Printer.
